Gemels® OverCenter Valve, Single Effect ½” SAE/ORB Ports, 16 GPM
$119.95
Gemels® OverCenter Valve, Single Effect ½” SAE/ORB Ports, 16 GPM
In stock
Gemels® SKU: NVO2S030000
The SCBV (VOSE) series valves are designed for hydraulic applications where automatic selection of the higher pressure line is required, ensuring system continuity and operational safety. They are particularly suitable for control circuits, redundant systems, and industrial applications.
The shuttle valve configuration allows automatic flow selection between two inlets directed to a single outlet, without the need for external control. This principle enables efficient management of pressure lines in hydraulic systems. In specific system configurations, it can be used alongside a single acting over-center valve for lifting, supporting pressure signal management.
Manufactured in carbon steel and designed for high pressure operation, SCBV valves ensure reliable performance even under demanding conditions. The SAE threaded connections allow easy and standardized integration into hydraulic circuits.
Benefits:
- Load holding
- Zinc-plated carbon steel body
Specifications:
- Flow rating: 16 GPM
- Pressure Rating: 5075 psi
- Relief Setting: 4350 psi
- Pilot Ratio: 4:25:1
| Weight | 3 lbs |
|---|---|
| Dimensions | 6.04 × 1.18 × 2.36 in |
| Flow Rating | 16 GPM |
| Pressure Rating (PSI) | 5,075 PSI |
| Relief Setting (PSI) | 4,350 PSI |
| Pilot Ratio | 4:25:1 |
